Mastering the Art of Electrical Connections with Wagobox Junction Boxes
June 6, 2024

Mastering the Art of Electrical Connections with Wagobox Junction Boxes

In the world of electrical installations, the Wagobox Junction Box has emerged as a game-changer. This innovative product, along with its variants - the 221-4 Wagobox and the Wagobox Light, has revolutionized the way electricians work. This blog post will delve into the workings of these devices and explain why they are indispensable tools for every electrician.

Understanding the Original Wagobox Junction Box

The original Wagobox Junction Box is a compact, versatile, and user-friendly electrical junction box designed to simplify the process of connecting cables. It’s a product of Wago and designed by Raymond Brewer, the founder of Connexbox Ltd who also designed the 221-4 series, Wagobox Light, XL, XLA and Capsule junction boxes.

The Wagobox Junction Box works in conjunction with Wago’s 222 and 773 series connectors, providing a secure and safe enclosure for wire connections. Here’s a step-by-step guide on how it works:

  • Preparation: Strip the insulation from the cable to be connected, ensuring they are clean and straight
  • Connection: Insert the stripped wires into the Wago connectors. These connectors use a spring clamp mechanism, which securely holds the wires once they are inserted.
  • Enclosure: Place the connected wires into the Wagobox Junction Box. The box has flexible entry points that can accommodate cables of various sizes.
  • Securing the Box: Close the lid of the Wagobox Junction Box. It has a latching mechanism that securely locks the box, protecting the connections inside. Attach a cable tie to the hole to make it maintenance free.

    •

    The 221-4 Wagobox: A Step Up in Connection Technology

    The 221-4 Wagobox is a variant of the standard Wagobox, designed to work with Wago’s 221 series connectors. These connectors can accommodate up to five stripped wires, making them ideal for more complex installations. Here’s how to use it:



  • Preparation: Strip the insulation from the cable to be connected, ensuring they are clean and straight.
  • Connection: Insert the stripped cable into the 221 series connectors. These connectors use a lever mechanism, which securely holds the wires once they are inserted and the lever is closed. Or instead you can insert an earth connector terminal to the middle of the box to add the 221-415 connector for extra connection.
  • Enclosure: Place the connected wires into the 221-4 Wagobox. The box has flexible entry points that can accommodate cables of various sizes.
  • Securing the Box: Close the lid of the 221-4 Wagobox. It has a latching mechanism that securely locks the box, protecting the connections inside.  Include a cable tie to make the box maintenance free.

    •

    The Wagobox Light: Simplifying Light Installations

    The Wagobox Light is a smaller version of the standard Wagobox, designed specifically for light installations. It works in conjunction with Wago’s 224 series connectors and, with a mounting carrier installed, also works with the 221-2411 series connectors, providing a secure and safe enclosure for cable connections. Here’s how it works:



  • Preparation: Strip the insulation from the wires to be connected.
  • Connection: Insert the stripped wires into the 224 series connectors. These connectors use a push-wire connection, which securely holds the cables once they are inserted. Or with a mounting carrier installed, you can use the 221-2411 series connecters. These include a lever clamp to secure the wire.
  • Enclosure: Place the connected wires into the Wagobox Light. The box is compact and can be easily installed in a ceiling void or behind a light fitting.
  • Securing the Box: Close the lid of the Wagobox Light. It has a snap-close lid that securely locks the box. Include a cable tie to make the box maintenance free.

    • In conclusion, the Wagobox Junction Box and its variants, the 221-4 Wagobox and the Wagobox Light, are transforming the field of electrical installations. Their innovative design, ease of use, and safety features make them indispensable tools for electricians. Whether you’re a seasoned professional or a novice in the field, these devices are sure to make your work easier, safer, and more efficient.

    For even more information on the Wagobox see here for the makers of the enclosures: https://www.connexbox.com
